Rodagon-M42 LINOS lenses

Rodagon-M42 machine vision lenses: high quality lenses for demanding applications.
For line-scan (linear) cameras and large format sensor 2D cameras.

Rodagon M42 series with integrated focusing.

The Rodagon lenses are successfully implemented in many different machine vision applications for many years already. Now, the Rodagon family grows further and Qioptiq sets a new standard with the Rodagon M42 series in terms of price-performance-ratio.

The new Rodagon M42 series is available with 40, 50 or 60 mm focal length. The lenses feature integrated manual focusing that can be adjusted precisely and fixed by a locking ring and additional clamping screws. Even strong vibrations will not cause defocusing of the setup. The flange focal distance of the M42 mount is specifically optimized for industrial line scan cameras like UNIIQA, Linea or Racer made by leading camera manufacturers to cover the complete magnification range of typical machine vision applications. The fixed aperture of the Rodagon M42 lenses further enhances the robustness as no accidental change of aperture setting is possible. The result is a simple and robust as well as cost-effective system comprising of camera and lens without any moving parts.

Chart of Rodagon-M42 models:

Here you can check our range of machine (artificial) vision line-scan cameras.

We are the distributors in Portugal and Spain from Excelitas-Qioptiq-LINOS.
